Two different pad openings are used:

Standard Pad Opening is 70um x 75um where 70um is the width of the opening (width as seen from the die side) and 75um is the depth of the opening (from the die side into the silicon).

Double Pad or Elephant Pad Opening is 130um x 75um where 130um is the width of the opening (width as seen from the die side) and 75um is the depth of the opening (from the die side into the silicon). The Double Pad openings are represented with two opening coordinates and two pad numbers. Double Pads are used only for supply and can be identified by the words ´Double Pad´ or ´Elephant Pad´ in the Comment column.

Product Features

TypeMain product features
SAK-TC275TP-64F200WHigh Performance Microcontroller with three CPU cores
Lockstepped shadow cores for one TC1.6P and for TC1.6E
64-Channel DMA Controller with safe data transfer
High performance on-chip bus structure
